性能參數Parameter

 挖掘深度Maximum digging depth

mm

2760

 挖掘高度Maximum digging height

mm

3850

 回轉半徑Minimum swing radius

mm

2120

 發動機型號 Engine model

新柴

4D27

發動機功率

KW

36.8

 標準鏟斗容量Bucket capacity

m3

0.1

 工作壓力 Working pressure

MPa

22

 接地比壓 Ground specific pressure

KPa

30

 回轉速度Rotary speed

rpm

10

 行走速度Walking speed

km/h

2.5

 履帶寬度 Track width

mm

250

 離地間隙Ground clearance

mm

510

 爬坡能力Climbing ability

°

<30

 全車總寬Width

mm

1600

 全車總高Height

mm

2450

 全車總長Length

mm

4320

 整機重量Weight

kg

2780
